Call it what you will - a trail riding heavy hitting cross-country bike, or a lightning fast trail bike, either way, LINEFINDER is a thoroughly modern, highly efficient, supremely capable rocket that’s made to go fast & rip hard.
120mm of fully-active four bar linkage tuned rear suspension paired with a 130 or 140mm fork up front provides supremely confident descending and climbs like a goat. Because not all trails point downhill but we always like to go fast, LINEFINDER is as much fun on the pedal heavy parts as it is on the gnarly bits.
Quality design and construction make it perfect for the long haul.
AVAILABLE FOR PREORDER NOW. SHIPPING EARLY OCTOBER 2024.
Regular price$3,999.00
/
SHIP TO YOUR HOME
120MM
REAR TRAVEL
TUNED
FOUR BAR PLATFORM
29 X 2.4
TIRE CLEARANCE
REACH ADJUST
+/- 10MM FORE AND AFT
BUILD KIT
SHIMANO XT
FRAME
LINEFINDER LTD CARBON 120MM
REAR SHOCK
Rockshox deluxe ultimate rct
FORK
rockshox pike ultimate 130mm
HANDLEBAR
oneup ALUMINUM 20MM RISE 35MM CLAMP
STEM
oneup STEM 42MM
SEATPOST
oneup v3 dropper post
SADDLE
SELLE MODEL Y
GRIPS
ONEUP THIN GRIPS
SHIFTER
SHIMANO XT 12SPD
REAR DERAILLEUR
SHIMANO XT 12SPD
CRANKSET
SHIMANO XTr 12SPD
CASSETTE
SHIMANO XT 12SPD 10-51
CHAIN
SHIMANO HG 12SPD
BRAKES
SHIMANO XT M8120
BRAKE ROTORS
SHIMANO 180MM CL
WHEELSET
BOYD STUMPHOUSE
FRONT TIRE
MAXXIS MINION DHF 29X2.5 EXO
REAR TIRE
MAXXIS AGGRESSOR 29X2.3 EXO
HEADSET
FSA NO.55R 1.5
BOTTOM BRACKET
PRAXIS WORKS T47
WHEEL SIZE
29"
REAR TRAVEL
120MM
FRONT TRAVEL
130MM/140MM
ISCG TABS
ISCG05
MAX CHAINRING
32T
SEATPOST DIAMETER
31.6MM
SEAT CLAMP
36.6MM
BB SET
T-47
SHOCK SPEC
185X50 TRUNION
HEADSET
FSA NO.55R 1.5
MAXIMUM TIRE CLEARANCE
29" X 2.4"
REAR AXLE
12MM X 148MM BOOST 1.5 THREAD
REAR DISC
POST MOUNT 180MM
DERAILLEUR HANGER
SRAM UDH
FRAME SIZE
SMALL
SEAT TUBE LENGTH
390MM
EFFECTIVE TOP TUBE LENGTH
577.8MM
HEAD TUBE LENGTH
90MM
CHAINSTAY LENGTH
430MM
EFFECTIVE SEAT TUBE ANGLE
75.1°
HEAD TUBE ANGLE
65.5°
WHEELBASE
1153.4MM
FORK OFFSET
44MM
BB DROP
32MM
FRONT CENTER
605MM
STACK
605MM
REACH
420/430MM
ACTUAL SEAT TUBE ANGLE
68°
ESTIMATED BB HEIGHT
340MM
CRANK LENGTH
170MM
FRAME SIZE
MEDIUM
SEAT TUBE LENGTH
420MM
EFFECTIVE TOP TUBE LENGTH
600MM
HEAD TUBE LENGTH
100MM
CHAINSTAY LENGTH
430MM
EFFECTIVE SEAT TUBE ANGLE
75.1°
HEAD TUBE ANGLE
65.5°
WHEELBASE
1177.5MM
FORK OFFSET
44MM
BB DROP
32MM
FRONT CENTER
748MM
STACK
615MM
REACH
440/450MM
ACTUAL SEAT TUBE ANGLE
68°
ESTIMATED BB HEIGHT
340MM
CRANK LENGTH
170MM
FRAME SIZE
LARGE
SEAT TUBE LENGTH
450MM
EFFECTIVE TOP TUBE LENGTH
628MM
HEAD TUBE LENGTH
110MM
CHAINSTAY LENGTH
430MM
EFFECTIVE SEAT TUBE ANGLE
75.1°
HEAD TUBE ANGLE
65.5°
WHEELBASE
1207MM
FORK OFFSET
44MM
BB DROP
32MM
FRONT CENTER
777MM
STACK
625MM
REACH
465/475MM
ACTUAL SEAT TUBE ANGLE
68°
ESTIMATED BB HEIGHT
340MM
CRANK LENGTH
170MM
FRAME SIZE
EXTRA LARGE
SEAT TUBE LENGTH
480MM
EFFECTIVE TOP TUBE LENGTH
655MM
HEAD TUBE LENGTH
120MM
CHAINSTAY LENGTH
430MM
EFFECTIVE SEAT TUBE ANGLE
75.1°
HEAD TUBE ANGLE
65.5°
WHEELBASE
1236MM
FORK OFFSET
44MM
BB DROP
32MM
FRONT CENTER
806.5MM
STACK
635MM
REACH
490/500MM
ACTUAL SEAT TUBE ANGLE
68°
ESTIMATED BB HEIGHT
340MM
CRANK LENGTH
170MM
SM
RECOMMENDED HEIGHT:
5'0" - 5'5"
MD
RECOMMENDED HEIGHT:
5'5" - 5'10"
LG
RECOMMENDED HEIGHT:
5'9" - 6'1"
XL
RECOMMENDED HEIGHT:
6'0" - 6'5"
The serial number is located underneath the bottom bracket of the bicycle.
All of our bikes and frame sets are engineered and built to be ridden at the highest levels of competition or play. We seal all of our bikes with a 3 year warranty against manufacturer defect in materials or craftsmanship. See warranty details on our Register Your Bike page.
You can buy any of our products directly from our website - shipped directly to your home or local bike shop. Alternatively, you can purchase our bikes in store at select retailers. Visit our dealer locator to find your local Van Dessel retailer:
